Liquid Dosing Pump

Name: Liquid Dosing Pump
Brand: Mini Dose Solution Pumps
Price: 8200 INR
Availability: InStock

Price 8200 INR/ Piece

Get a Price/Quote

MOQ : 1 , , Piece

Liquid Dosing Pump Specification

Caliber
As per model

Theory
Electromagnetic Pump

Working Temperature
Up to 60C

Control System
Manual / Digital Controller

Voltage
220-240 V AC

Speed
Fixed/Adjustable

Max Suction
2-3 meters

Noise Level
< 50 dB

Head Size
Up to 120 m

Mounting Type
Wall or Base Mounted

Discharge Pressure
Up to 10 bar

Flow Rate
0.5 to 15 LPH

Features
Corrosion Resistant, Low Maintenance, Adjustable Stroke

Inlet/Outlet
1/2 BSP or NPT

Frequency
50/60 Hz

Material
Polypropylene, PVDF, SS316

Structure
Diaphragm Type

Power
Electric Volt (v)

Standard
IP65 Rated, ISO 9001

Fuel Type
None (Electric)

Pressure
Up to 10 bar

Usage
Chemical, Water Treatment

Application
Other

Suction Type
Positive

Seals Type
PTFE / Viton

Priming
Self-priming

Pump Type
Solenoid Driven

Capacity
Up to 15 LPH

Diaphragm Material
PTFE

Stroke Adjustment Range
10% to 100%

Connection Type
Threaded or Hose

Pump Head Material
PVDF/SS316/PP depending on application

Ambient Temperature
up to 45C

Cable Length
1.5-2 meters

Weight
Approx. 4-7 kg

Display
Digital (on selected models)

Enclosure Protection
IP65

Liquid Dosing Pump Trade Information

Minimum Order Quantity
1 , , Piece

Supply Ability
100 Pieces Per Day

Delivery Time
2-3 Days

Main Domestic Market
All India

About Liquid Dosing Pump

Back since year 2011, we are engrossed in manufacturing and supplying quality assured Liquid Dosing Pump to our prestigious clients. It is a pump that is used to deliver a precise quantity of liquids at controlled interval. This pump is made from superior grade materials that are in compliance with international standards. In addition to this, Liquid Dosing Pump is available at highly reasonable rates keeping in mind budget of customers.

Features:

Can be used in cosmetics and food industries
Sturdy construction
High durability

Versatile Pumping Solution

Designed for diverse applications, the Liquid Dosing Pump with Display offers reliable dosing for industries such as water treatment, cosmetics, food, and chemicals. Its adaptable head material (PVDF, SS316, or PP) ensures chemical compatibility and durability, while the selection of manual or digital displays streamlines operation and monitoring.

Built for Corrosion Resistance and Safety

With a diaphragm crafted from PTFE and seal options of PTFE or Viton, this dosing pump excels in resisting aggressive chemicals and ensuring long-term performance. The IP65 enclosure protects against dust and water, while the sturdy structure and low maintenance needs contribute to its operational safety and robustness.

Advanced Controls for Precise Dosing

This pump provides stroke adjustment between 10% and 100%, with a flow rate up to 15 LPH and discharge pressure reaching 10 bar. Control systems can be manual or digital, supporting both fixed and adjustable speeds, ensuring precise and repeatable dosing for process accuracy and resource efficiency.

FAQ's of Liquid Dosing Pump:

Q: How does the Liquid Dosing Pump operate and where can it be used?

A: The Liquid Dosing Pump operates on an electromagnetic solenoid-driven mechanism, which ensures accurate dosing of liquids. It is commonly used in water treatment, cosmetics, food processing, and chemical industries across India, offering reliable operation in challenging environments.

Q: What materials are available for the pump head and diaphragm, and how do I select them for my application?

A: Pump heads are available in PVDF, SS316, or polypropylene, each chosen based on the fluid's chemical compatibility. The diaphragm is made of PTFE, renowned for its durability and resistance to aggressive chemicals. Selecting the appropriate material ensures both long service life and safe operation for specific dosing tasks.

Q: When should I adjust the stroke, and what is the adjustment range?

A: Stroke adjustment is recommended when the required dosing volume or flow rate changes. The stroke can be set between 10% and 100%, allowing operators to precisely control the amount of liquid delivered in each cycle depending on process or application requirements.

Q: What is the process for installing the dosing pump, and what mounting options are available?

A: Installation is straightforward with options for wall or base mounting to suit various sites. The pump offers threaded or hose connections (1/2 BSP or NPT), and its self-priming design simplifies setup. It connects to standard 220-240 V AC power and is protected by a 1.5-2 meter cable for flexible placement.

Q: How does the digital display benefit daily operation and monitoring?

A: Selected models feature a digital display for enhanced monitoring and control, displaying operational parameters and allowing users to quickly adjust settings or troubleshoot. This enables more precise dosing, easier calibration, and greater transparency in daily operations.

Q: What are the advantages of using this pump regarding maintenance and operation costs?

A: The pump is engineered for low maintenance with corrosion-resistant materials, high-quality PTFE/Viton seals, and IP65 enclosure protection. These features minimize downtime, ensure reliable functioning, and reduce operational costs compared to conventional pumps.

Q: Is the pump suitable for variable environmental conditions, and up to what temperature can it function safely?

A: Yes, the pump is designed for robust performance in variable environments, operating safely at ambient temperatures up to 45C and working fluid temperatures up to 60C, ensuring reliability in both indoor and outdoor settings.
